Page 18
32
These values are only guidelines and actual conductor cross sections depend on manufacturer tolerances.
Crimp Tool Setting for HUMMEL Crimp Contacts (Crimp Tool 7.000.900.904)
See page 40 for crimp tool instructions
Crimp Tool for Connectors M 16
Part Number
Crimp Contact
Cross Section (mm
2
)
AWG
Crimp Tool Setting mm
Locator Setting
7.010.901.002
Crimp socket 1 mm
0,34
AWG 22
0,77
2
(0,34 – 1 mm
2
)
0,56
AWG 20
0,82
0,75
AWG 18
0,88
1,0
AWG 17
0,95
7.010.981.201
Crimp pin 1,25 mm
0,5
AWG 20
0,70
2
0,75
AWG 18
0,73
1,0
AWG 17
0,79
1,5
AWG 16
0,88
7.010.981.202
Crimp socket 1,25 mm
0,5
AWG 20
0,70
2
0,75
AWG 18
0,73
1,0
AWG 17
0,79
1,5
AWG 16
0,88
7.010.981.211
Crimp pin 1,25 mm
0,34
AWG 22
0,80
B9
0,5
AWG 20
0,84
0,75
AWG 18
0,90
1,0
AWG 17
1,00
1,5
AWG 16
1,10
7.010.981.212
Crimp socket 1,25 mm
0,34
AWG 22
1,00
B10
0,5
AWG 20
1,04
0,75
AWG 18
1,10
1,0
AWG 17
1,20
1,5
AWG 16
1,30
7.010.981.601
Crimp pin 1,6 mm
0,34
AWG 22
0,80
6
0,56
AWG 20
0,84
0,75
AWG 18
0,90
1,0
AWG 17
1,00
1,5
AWG 16
1,10
7.010.981.602
Crimp socket 1,6 mm
0,34
AWG 22
0,83
9
0,56
AWG 20
0,90
0,75
AWG 18
0,97
1,0
AWG 17
1,02
1,5
AWG 16
1,10
7.010.982.001
Crimp pin 2 mm
1,0
AWG 17
1,35
4
1,5
AWG 16
1,45
2,5
AWG 14
1,60
7.010.982.002
Crimp socket 2 mm
1,0
AWG 17
1,35
5
1,5
AWG 16
1,45
2,5
AWG 14
1,60
Dimensions and specifications may be changed without prior notice
