New Era Pump Systems Inc.

www.SyringePump.com

Model NE-1000 Multi-Phaser™

Publication #1200-01

45

08/01/14

12.

Appendix

12.1

RS-232 Command Summary

=>
DIA [ < float > ]

Syringe inside diameter

PHN [ < phase data > ]

Program Phase number

FUN [ < phase function > ]

Program Phase function

< phase function > =>

RAT

Pumping rate. ‘RATE’

FIL

Fill syringe to volume dispensed. ‘FILL’

INC

Increment rate. ‘INCR’

DEC

Decrement rate. ‘DECR’

STP

Stop pump. ‘STOP’

JMP

Jump to Program Phase. ‘JP:nn’

PRI

Sub-Program Selection Input. 'Pr:In'

PRL

Sub-Program Start Label definition. 'Pr:nn'

LPS

Loop starting Phase. ‘LP:ST’

LOP

Loop to previous loop start ‘nn’ times. ‘LP:nn’

LPE

Loop end Phase. ‘LP:EN’

PAS

Pauses pumping for ‘nn’ seconds. ‘PS:nn’

PAS [n.n]

Pauses pumping for 'n.n' seconds. 'PS:n.n'

IF

If Program input low, jump to Program Phase. ‘IF:nn’

EVN

Set event trigger. ‘Et:nn’

EVS

Set event square wave trigger. 'ES:nn'

EVR

Event trigger reset. ‘Et:RS’

CLD

Clear total dispense volume. ‘CLR.D’

TRG

Override default operational trigger configuration ‘tr:aa’

BEP

Sound short beep. ‘BEEP’

OUT { 0 | 1 }

Set programmable output pin. ‘OUT.n’

RAT [C | I ] [ [ UM | MM | UH | MH ] ] Pumping rate
VOL [ | ]

Volume to be Dispensed, or set Volume units

DIR [ INF | WDR | REV | STK ]

Pumping direction

RUN [ ]

Starts the Pumping Program

[E [] ]

Pumping Program event trigger

PUR

Start purge

STP

Stop/pauses the Pumping Program or purge

DIS

Query volume dispensed

CLD { INF | WDR }

Clear volume dispensed

SAF [ [ [ ] ] ]

Safe communications mode

LN [ 0 | 1]

Low motor noise mode

AL [ 0 | 1]

Alarm buzzer mode

PF [ 0 | 1]

Power failure auto-restart mode

TRG [ FT | FH | F2 | LE | ST | T2 | SP | P2 | RL | RH | SL | SH | OF ]

Operational trigger default mode

DIN [ 0 | 1]

Directional input control mode

ROM [0 | 1]

Pump Motor Operating TTL output mode

LOC [ P ] [ 0 | 1]]

Keypad lockout mode or Program Entry Mode lockout

BP [ 0 | 1]

Key and Notification beep mode

OUT 5 { 0 | 1 }

Set TTL output level

IN { 2 | 3 | 4 | 6 }

Query TTL input level

BUZ [ 0 | { 1 [ < n > ] } ]

Buzzer control

VER

Query firmware version

System Commands: Valid regardless of current network address

*ADR [ [] [ B ] ]

Network address and baud rate

*ADR [ DUAL | RECP | ALTR ]

Set Reciprocating, Dual, or Alternating pumping mode

*RESET

Resets pump. Clears program memory and resets setup.

------------------------------------------------------------------------------------------------------------------------------
Network Command Burst => * [Network Command Burst]
- Communicate simultaneously with multiple pumps on a pump network.

Any command preceded by the asterisk symbol ‘*’ bypasses the pump network address and Safe mode.
