ALARM SETUP
AL [
Set/query alarm setup mode. Set alarm enables or disables alarm buzzer mode.
POWER FAIL SETUP
PF [
Set/query Power Failure mode. Set Power Failure enables or disables Power Failure mode.
TTL I/O OPERATIONAL TRIGGER DEFAULT SETUP
TRG [
Set/Query TTL I/O Operational Trigger (Pin 2) default input configuration.
TTL I/O Operational Trigger is set to
FT
= Foot switch trigger (falling edge start/stop)
FH
= Foot switch hold (falling edge start, rising edge start)
F2
= Foot switch reverse (rising edge start/stop)
LE
= Level trigger (rising edge start, falling edge stop)
ST
= Start only trigger (falling edge start)
T2
= Start only trigger reversed (rising edge start)
SP
= Stop only trigger (falling edge stop)
P2
= Stop only trigger reversed (rising edge stop)
RL
= Start on low level
RH
= Start on high level
SL
= Stop on low level
SH
= Stop on high level
OF
= Trigger off (disabled)
TTL I/O DIRECTIONAL CONTROL INPUT SETUP
DIN [ 0 | 1 ]
Set/query directional control input setup
Settings => 0 = Falling edge: Infuse, Rising edge Withdraw
Same as "dr:rE" setting from the keypad.
Use this setting with the CBL-TTL-1, reciprocating pump cable, to create a 2 pump
continuous infusion system
1 = Falling edge: Withdraw, Rising edge Infuse
Same as "dr:dU" setting from the keypad.
Use this setting with the CBL-TTL-1, reciprocating pump cable, to create a 2 pump
dual pumping system
PUMP MOTOR OPERATING TTL OUTPUT CONFIGURATION
ROM [
Set/query Pump Motor Operating TTL output configuration (TTL pin 7)
Settings => 0 = Output is logic high only when the pump motor is operating (pumping).
1 = Output is logic high when the pump motor is operating (pumping) or when the
Pumping Program is executing a pause timer.
SET KEYPAD LOCKOUT
LOC [P] [
Set/query keypad lockout mode. Set keypad lockout disables changing any settings from the keypad
unless the "Lockout Disable Key" is inserted.
P [
Set/Query Program Entry Mode Lockout. Set Program Entry Mode Lockout prevents inexperienced
users from entering “Program Entry Mode” from the keypad. When enabled, only the Phase 1 ‘Rate’,
