New Era NE-1000 Multi-Phaser Programmable Syringe User Manual
Page 41
New Era Pump Systems Inc.
www.SyringePump.com
Model NE-1000 Multi-Phaser™
Publication #1200-01
36
08/01/14
All commands are upper case.
DIAMETER
DIA [
Set/query inside diameter of syringe. Set is only valid when the Pumping Program is not operating.
Setting the syringe diameter also sets the units for “Volume to be Dispensed” and “Volume
Dispensed”.
10.4.1
Program Function Commands
The following commands are relevant to the currently select Program Phase. Note: During a Pumping
Program’s operation, the currently selected Phase can change automatically.
PHASE NUMBER
PHN [
Set/query currently selected Program Phase:
Set:
Currently selected Phase is set to
the requested Phase is recalled from the non-volatile memory. Set is only valid if the Pumping
Program is not operating.
Query response:
Currently selected Phase.
PUMPING PROGRAM FUNCTION
FUN [
Set/query the Pumping Program Phase’s function.
This command is relevant to the currently selected Phase. Set is only valid if the Pumping Program is
not operating
For a more detailed description of Program commands, see sec. 9.3, Program Function Descriptions.
Rate Data Functions
When a Phase’s function is set to a “Rate Data Function”, use the ‘RAT’, ‘VOL’, and ‘DIR’
commands to setup the pumping parameters.
RAT
Pumping rate. ‘RATE’
FIL
Fill syringe to dispensed volume. ‘FILL’
INC
Increment rate. ‘INCR’
DEC
Decrement rate. ‘DECR’
Non-Rate Control Functions
STP
Stop pump. ‘STOP’
PAS
Pauses pumping for ‘nn’ seconds. ‘PS:nn’
PAS
Pauses pumping for 'n.n' seconds. 'PS:n.n'
PRI
Sub-Program Selection Input. 'Pr:In'
PRL
Sub-Program Start Label definition. 'Pr:nn'
LPS
Loop starting Phase. ‘LP:ST’
LPE
Loop end Phase. ‘LP:EN’
LOP
Loop to previous loop start ‘nn’ times. ‘LP:nn’
JMP
Jump to Program Phase. ‘JP:nn’
IF
If Program input TTL pin low, jump to Phase. ‘IF:nn’
EVN
Set event trigger trap. ‘EV:nn’
EVS
Set event square wave trigger trap. 'ES:nn'
EVR
Event trigger reset. ‘EV:RS’
CLD
Clear total dispense volume. ‘CLR.D’
TRG
Override Operational Trigger Default Mode, set to
BEP
Sound short beep. ‘BEEP’
OUT
Set programmable output pin. ‘OUT.n’
