Model NE-1000 Multi-Phaser™
Publication #1200-01 40 08/01/14
‘Volume’ and Pumping Direction can be changed. Cannot be enabled when the Pumping Program is
currently programmed with a multiple Phase Program.
SET KEYPAD AND NOTIFICATION BEEP
BP [ ]
Set/query keypad and notification beep mode. Set beep enables or disables beep mode.
10.4.4 General Control and Status Commands
TTL I/O OUTPUT SETTING
OUT
Sets TTL level on user definable output pin on the ‘TTL I/O’ connector.
Indicates pin number on ‘TTL I/O’ connector
Valid value: 5 (Program Output pin)
Query is not applicable.
TTL INPUT QUERY
IN
Queries TTL level of pin on ‘TTL I/O’ connector. Set is not applicable.
Indicates pin number on ‘TTL I/O’ connector
Valid values: 2, 3, 4, and 6.
Query response:
BUZZER
BUZ [ 0 | { 1 [ < n > ] } ]
Sets / queries buzzer
Set: 0 = Turn buzzer off;
1 = Turn buzzer on
if specified
If = 0, buzzer beeps continuously,
otherwise buzzer beeps times
if not specified, buzzer sounds continuously
Query response: { 0 | 1 }
0 = Buzzer off
1 = Buzzer is on continuously or beeping.
10.4.5 System Commands
SET PUMP NETWORK ADDRESS AND BAUD RATE
* ADR [
Set/query pump network address
B { 19200 | 9600 | 2400 | 1200 | 300 } will change the baud rate as indicated. NOTE: The command
response and all further communications will be at the specified baud rate.
Special communications modes
DUAL Sets the pump to Dual Pumping mode with a secondary pump.
RECP Sets the pump to Reciprocating Pumping mode with a secondary pump.
ALTR Sets Alternating pumping mode.
All special communications modes use 19,200 baud rate.
This is a special system command that will be accepted by the pump regardless of its current address or mode.
Once set, the pump will only respond to commands with the set address and at the specified baud rate.
