Multiquip LT12P - Manual (Page 47)

LT12 SERIES LIGHT TOWER • OPERATION MANUAL — REV. #12 (01/20/09) — PAGE 47
LT12 WIRING DIAGRAM — S/N 902149 TO 902625
GRN
BLK
CB6
15 AMP
BREAKER
(GFCI)
X
Y
240 VAC
AUX RECPT.
120 VAC
GFCI
RECEPT.
LINE
TB2
WHT
GRN
WHT
W
CHASSIS
GROUND
WHT
GND
G
NEU.
CB4
10 AMP
BREAKER
(LAMP 4)
CB3
10 AMP
BREAKER
(LAMP 3)
CB2
10 AMP
BREAKER
(LAMP 2)
CB1
10 AMP
BREAKER
(LAMP 1)
NEU. 120V IN OUTPUT
BALLAST #4
24µF@480V
CAPACITOR
NEU. 120V IN OUTPUT
BALLAST #3
24µF@480V
CAPACITOR
NEU. 120V IN OUTPUT
BALLAST #2
24µF@480V
CAPACITOR
NEU. 120V IN OUTPUT
BALLAST #1
24µF@480V
CAPACITOR
WHT
LOAD
NEUTRAL BUS
CB5
25 AMP
MAIN
BREAKER
RED
RED
RED
RED
YEL
YEL
YEL
YEL
BLK
BLK
J1 J2 J3 J4
GRN
BLK
BLK
BLK
BLK BLK BLK WHT WHT BLK WHT
BLK 16 AWG
BLK 16 AWG
BLK 16 AWG
BLK 16 AWG
WHT 14 AWG
GRN 16 AWG
WHT
GRN
YEL
YEL
YEL
YEL
6-WIRE COIL CORD
P/N 19955
BLK
BLK
BLK
BLK
BLK
BLK
BLK
BLK
RED
BLK
GRN
BLK
T-BAR ASSEMBLY
P/N 19954
CONTROL PANEL/BALLAST
ASSEMBLY P/N 29614
BLK
BLK
BLK
4
3
2
1
WHT
RED
RED
BLK
240 VAC
FROM GENSET
A
NOTES:
S/N 902625 AND BELOW
USE ONLY SCREW
TYPE CIRCUIT BREAKERS.
B 6-WIRE COIL CORD P/N 19955.
INSTALLED ON UNITS S/N 905512
AND BELOW.
B
A
C WIRE SIZE IS 12 AWG UNLESS
OTHERWISE SPECIFIED.
C
WHT
D
SOME UNITS MAY HAVE A 47K
½ WATT RESISTOR INSTALLED
ACROSS THE CAPACITOR
TERMINALS. OTHER UNITS MAY
HAVE THIS RESISTOR INTERNALLY
INSTALLED WITHIN THE CAPACITOR.
W
D
