PAGE 44 — LT12 SERIES LIGHT TOWER • OPERATION MANUAL — REV. #12 (01/20/09)
1
120 VAC
60 HZ
240 VAC
60 HZ
60 HZ 50 HZ
120 VAC
60 HZ
ROTOR
STATOR
EXCITATION
WINDING
C1
36µF@425V
EXCITATION
CAPACITOR
STATOR
WINDING
ROTOR
WINDINGS
FIXED FLOW
CURRENT
DIODE
BLACK
2
GREEN
4
WHITE
5
RED
RED
RED
BLK
GRN
WHT
RED
BLK
BLK
TB1
4
3
2
1
WHT
GRN
BLK
A
NOTES:
SQUARE TYPE 60 Hz GENERATOR
S/N 902148 AND BELOW, P/N 29643.
A
B
B
C1
35µF@425V
EXCIT
ATION
CAP
ACIT
OR
STARTING WITH S/N 902148 AND BELOW
,
USE ONLY 35µF@425 EXCITATION
CAPACITOR P/N GECAP35MF.
LINE 1
NEUTRAL
LINE 2
JUMPER
GENERATOR
TERMINAL
BOARD
C
SOME UNITS MAY HAVE TWO 18
CAPACITORS CONNECTED IN PARALLEL
µF
USE P/N GECAP18MF.
C1
18µF@425V
EXCIT
ATION
CAP
ACIT
OR
C2
18µF@425V
EXCIT
ATION
CAP
ACIT
OR
35µF
C
1
5
4
2
3
6
BLK
W1
W2
RED
WHT
GRN
WHT
CHASSIS
GND
V2
V1
U1
U2
LT12 WIRING DIAGRAM — S/N 902148 AND BELOW
