page 12 — Tp7X TILe SaW • operaTIon manuaL — rev. #0 (03/04/11)
general infOrMatiOn
The TP7X is a powerful, robust saw designed to
professionally handle large-sized cuts on ceramics, stone,
and masonry materials. A sturdy steel precision frame and
easily removable ABS water tray provides overall durability
and longevity.
This saw is equipped with a trusted 1 HP electric motor that
operates on standard 115 V power and is designed with
thermal overload and fan air cover protection.
An innovative water-cooled bearing assembly works in
conjunction with the water pump to keep key bearing
components running cooler.
The TP7X saw comes complete with premium blade and
high flow water pump.
Dry CuTTIng appLICaTIonS
The TP7X tile saw is shipped from the factory for wet-cutting
saw applications, however it can be used for dry-cutting
saw applications. The most import thing to remember is to
disconnect the water pump. The water pump is cooled by
the flow of water, and failure to disconnect the pump (when
running dry) will cause pump failure.
BLaDe appLICaTIonS
This saw has been designed to incorporate the use
of diamond blades as the cutting tool. The optimum
performance of this saw is best evidenced by using 7-inch
(178 mm) diamond blades that match the material being
cut. Ask your dealer, or call Multiquip about your specific
cutting application.
NOTICE
never have the water pump engaged when dry cutting
applications are involved.
aCCeSSorIeS/repLaCemenT parTS
If desired, the TP7X tile saw can be equipped with a support
stand. This stand is ideal when the saw needs to be placed
on a secure reliable platform.
FeaTureS
„ rugged portable Frame assembly — Sturdy steel
frame design with handles for easy transport.
„ electric Induction motor — UL/CSA approved 115 V
60 Hz, 1 HP electric motor with thermal overload and
fan cover protection.
„ Water Tray — Sturdy ABS water tray that is easily
removable for cleaning.
„ Cutting Table — Rugged cast aluminum table with
heavy-duty injected molded rubber padding and
extension table. Industrial ball bearing rollers ensure
smooth, precise cart movement.
„ Water pump — Powerful submersible pump provides
high volume water flow.
„ Water-Cooled Blade Shaft Bearing assembly — High
flow water circulating system designed to keep crucial
bearing components running cooler.
„ Blade guard — Hardy cast guard with blade brushes
designed to evenly distribute water to the blade, and to
easily position for blade changes.
„ Diamond Blade — 7-inch (178 mm) premium tile blade
included.
