PAGE 30 — MQ SP4030 SAW • OPERATION MANUAL — REV. #0 (01/22/09)
WATER DELIVERY SYSTEM (OPTION)
1. Connect the water supply hose to the water inlet
(garden hose) fitting on the left side of the saw (Figure
5, Item 21).
2. Verify that the water hose on the saw is connected to
the blade guard (Figure 14), and that the water hoses
or tubes are pointed into both blade flanges.
3. Ensure that the hose ends maintain a 45 o angle and
maintain a light contact with the surface of the blade
(Figure 17).
4. The lever on the left side of the control panel regulates
water flow volume. The lever on the right side of the
control panel turns the water ON and OFF.
5. If the saw is equipped with an optional water pump,
the ON/OFF switch is located on the control panel next
to the water ON/OFF control valve.
WATER DELIVERY SYSTEMS
CAUTION
When storing the saw where temperatures may drop
below freezing, blow out the water lines to prevent
damage to the water delivery system.
