Multiquip SP2S20H20A - Manual (Page 81)

SP213H20A / SP2S20H20A SAWS — OPERATION AND PARTS MANUAL — REV. #1 (05/17/10) — PAGE 81
BATTERY ASSY.
NO PART NO PART NAME QTY. REMARKS
1 4671 BATTERY, WET GR.U1, GT-X GOLD LA 1
2 28096-001 BRACKET BATTERY 1
3 28095-401 BATTERY HOLD DOWN KIT 425-405 1
4 28093-001 CABLE, BATTERY POS 6GA X 42” RING TONGUE 1
5 28094-001 STRAP, GROUND 1
6 0131 A SCREW, HHC 1/4-20 X 3/4 2
7 0948 WASHER, FLAT SAE 1/4 2
8 0949 NUT, HEX FINISH 1/4-20 PLATED 2
9 0655 SCREW, HHC 5/16-18 X 3/4 3
10 0161 D NUT, HEX FINISH 5/16-18 3
11 0161 C WASHER, LOCK 5/16 MED. 3
12 0300 B WASHER, FLAT SAE 5/16 6
13 0181 B WASHER, LOCK 1/4 MED. 2
BATTERY ASSY.
