PAGE 6 — SP213H20A / SP2S20H20A SAWS — OPERATION AND PARTS MANUAL — REV. #1 (05/17/10)
SPECIFICATIONS
* Nominal Mass: Mass without blade, all fluid tanks empty, any optional parts removed.
** Maximum Operating Mass: Includes blade, all fluid tanks full, any necessary components installed.
*** Hand/Arm Vibration (at handle) results with SP2 Saw cutting cured concrete at a depth of 38.1mm (1-1/2 in.)
with 508 mm (20 in.) blade at FULL THROTTLE.
Specifications Table 1.
SP2 (Push) SP2 (Self-Propelled)
Saw SP213H20A SP2S20H20A
Blade Capacity 508 mm (20 in.)
Cutting Depth 191 mm (7.5 in.)
Arbor Diameter 191 mm (7.5 in.)
Front Wheels 125 mm Dia. x 50 mm Wide (5 in. x 2 in.)
Rear Wheels 203 mm Dia. x 50 mm Wide (8 in. x 2 in.)
Nominal Mass* 141 kg (310 lbs.) 173 kg (380 lbs.)
Maximum Operating Mass**
lbs. (kg)
170 kg (373 lbs.) 201 kg (443 lbs.)
Sound Pressure at
Operator’s Position
96 dB 88.8 dB
Hand/Arm Vibration (At
Handle)***
9.81 ms -2 5.61 ms -2
Engine
Honda 13 HP
GX390K1QWT2
Gasoline Engine
Honda 20 HP
GX620TXF2
Gasoline Engine
