SP213H20A / SP2S20H20A SAWS — OPERATION AND PARTS MANUAL — REV. #1 (05/17/10) — PAGE 75
WATER SYSTEM ASSY.
NO PART NO PART NAME QTY. REMARKS
2 23255-004 HOSE, WATER 1/2 X 37 1
3 23566-001 FITTING, PLASTIC 90 1/2MP X 1/2BARB 1
4 23259-001 VALVE, BALL 1/2 MPT BRASS NIBCO T585-70 1
5 23254-001 FITTING, NIPPLE 1/2MP X 2 GALV. 1
6 16378-009 U-BOLT W/NUTS 1
7 15544 FITTING, BRASS 1/2FP-3/4F GRDN., STR 1
8 24778-001 FITTING, BRASS 1/2 BARB X 3/4 GRDN 1
9 1662 TIE, CABLE TY-RAP BLACK 2
10 28861-501 TRIM KIT, WATER TANK RUBBER 1
11 28089-001 TANK, 5 GAL. WATER 1
12 27040-001 HOSE, 19 IN. VINYL WATER TANK 1
13 28861-001 CORD, TANK RETAINER 1
14 28860-001 KNOB 1
15 06499-004 HHCS 1/4-20 x 1/2 1
WATER SYSTEM ASSY.
