SP213H20A / SP2S20H20A SAWS — OPERATION AND PARTS MANUAL — REV. #1 (05/17/10) — PAGE 115
PISTON ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 13010ZF6003 RING SET, PISTON (STD) 1
1 13011ZF6003 RING SET, PISTON (OS 0.25) (OPTIONAL) 1
1 13012ZF6003 RING SET, PISTON (OS 0.50) (OPTIONAL) 1
1 13012ZF6005 RING SET, PISTON (OS 0.50) (OPTIONAL) 1
1 13013ZF6003 RING SET, PISTON (0.75) (NIPPON) 1
2 13101ZF6W00 PISTON (STD) 1
2 13102ZF6W00 PISTON (OS 0.25) (OPTIONAL) 1
2 13103ZF6W00 PISTON (OS 0.50) (OPTIONAL) 1
2 13104ZF6W00 PISTON (0.75) (OPTIONAL) 1
3 13111ZF6W00 PIN, PISTON 1
4 13200ZE3010 ROD ASSY., CONNECTING (STD) ........................ 1 ......... INCLUDES ITEM W/ *
4 13200ZE3315 ROD ASSY., CONNECTING(US 0.25) (OPT.) ........ 1 ......... INCLUDES ITEM W/ *
5 * 90001ZE8000 BOLT, CONNECTING ROD 2
6 90601ZE3000 CLIP, PISTON PIN (20MM) 2
HONDA GX390K1QWT2 ENGINE — PISTON ASSY.
