MAYCO LS300 CONCRETE PUMP • OPERATION AND PARTS MANUAL — REV. #4 (06/21/10) — PAGE 93
AXLE ASSY.
AXLE ASSY. (RIGHT/LEFT)
NO. PART NO. PART NAME QTY. REMARKS
1 516931 AXLE, TORSION BAR ASSY. 1
2 EM092305 BRAKE ASSY COMPLETE, RIGHT ................ 1 .............. INCLUDES ITEMS W/#
2 EM092306 BRAKE ASSY COMPLETE, LEFT .................. 1 .............. INCLUDES ITEMS W/%
.......................................................................................... SEE NOTE BELOW
3 363198 OIL SEAL 1
4 363196 INNER BEARING CONE 2 IN. 1
5 383911 INNER BEARING CUP 2 IN. 1
6#% 363909 WHEEL STUD 1/2 IN. - 20 UNF PRESS IN 8
7 363239 HUB AND DRUM ASSY. 2
8 363916 OUTER BEARING CONE 1
9 363420 OUTER BEARING CUP 1
10 568326 LOAD WASHER 1 IN. T5 HP 1
11 363257 SLOTTED NUT, 1 IN. UNF 2
12 363258 COTTER PIN 3/16 IN. X 1-1/2 2
13 EM515479 RIM AND TIRE 2
14 26519 WHEEL LUG NUTS 1/2 UNF 60 CON 8
15 516482 GREASE CAP 2
16 EM963692 CAPSCREW, 1/2-13X1-1/2 HHCS 4
17 EM621 WASHER, 1/2" 8
18 EM092305 NUT, LOCK 1/2" 4
RIGHT AND LEFT SIDE AXLE
ASSEMBLIES ARE IDENTICAL WITH
THE EXCEPTION OF THE BRAKE
ASSEMBLY.
