MAYCO C30HDZ PUMP — OPERATION AND PARTS MANUAL — REV. #12 (04/03/12) — PAGE 61
C30HDZ CONCRETE PUMP
W/ SYSTEM
1 Units
P/N DESCRIPTION QTY.
EM14904 PISTON CUP KITS 6
EM18804 4 1/2" STEEL BALL 4
EM14818 4" STEEL BALL 4
EM14903 BALL STOP PIN KIT 6
EM18801 0-RING MANIFOLD 10
EM14308 CHAIN 1
EM26313 HALF LINK 2
EM26314 MASTER LINK 2
EM14334 COMPENSATOR SPRING 1
EM14408 BRONZE RING 2
EM903092 CAM ROLLER BEARING 2
EM14315 V-BELT 2
EM14842 LOWER SEAT 2
EM14843 UPPER SEAT 2
EM26310 CLUTCH LINING 2
EM18409 O-RING 10
EM20763 FUEL FILTER 2
EM20328TKIT BEARING KIT 2
EM28004DD REDUCER 3" X 2" 1
EM23946 3" ELBOW 1
EM28904 3" CLAMP 2
EM289041 3" GASKETS 4
EM14159 HOPPER SCREEN 1
SUGGESTED SPARE PARTS
C30HDZ CONCRETE PUMP
W/ SYSTEM
3 Units
P/N DESCRIPTION QTY.
EM14904 PISTON CUP KITS 10
EM18804 4 1/2" STEEL 10
EM14818 4" STEEL BALL 10
EM14903 BALL STOP PIN KITS 12
EM18801 MANIFOLD O-RINGS 25
EM14308 CHAINS 3
EM26313 HALF LINK 10
EM26314 MASTER LINK 10
EM14334 COMPENSATOR SPRING 2
EM14408 BRONZE RING 4
EM903092 CAM ROLLER BEARING 2
EM14315 V-BELT 6
EM14842 LOWER SEAT 6
EM14843 UPPER SEAT 6
EM26310 CLUTCH LINING 3
EM18409 O-RING 20
EM20763 FUEL FILTER 6
EM20328TKIT BEARING KIT 2
EM28004DD REDUCER 3" x 2" 2
EM23946 3" ELBOW 2
EM28904 3" CLAMP 4
EM289041 3" GASKET 10
EM14159 HOPPER SCREEN 2
EM14300 CAM 1
EM14801 T-MANIFOLD 1
EM14819 Y-MANIFOLD 1
EM14335 PISTON ROD 2
EM26788 REMOTE SWITCH 1
EM903176 CONN. ROD BEARING 1
EM14807 PUMP CYLINDER 2
EM18800 COMPENSATOR CYLINDER 2
EM14320 CLUTCH 1
Part number on this Suggested
Spare Parts List may super cede/
replace the P/N shown in the text
pages of this book.
NOTE
