MVH306D/DS PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #11 (02/04/14) — PAGE 69
STARTING MOTOR & DYNAMO ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 11436277011 STARTER (S114 - 414A) ..................................1 ............ INCLUDES ITEMS W/ *
2 * 11438177110 ARMATURE 1
3 * X2114811000 WASHER KIT, THRUST 1
4 * X2114715500 STOPPER SET, PINION 1
5 * 11438177130 COIL ASSY, FIELD 1
6 * 11438177140 COVER, REAR 1
7 * 11437177160 HOLDER ASSY, BRUSH 1
8 * 11437179040 BRUSH (-) 2
9 * 11437179050 BRUSH (+) 1
10 * 11437179060 SPRING, BRUSH 4
11 * X2114455080 PINION ASSY. 1
12 * 11438177150 HOUSING ASSY., GEAR 1
13 * 11437177170 COVER KIT, DUST 1
14 * X2114560130 LEVER KIT, SHIFT 1
15 * X2114275010 SWITCH ASSY, MAGNET 1
16 * X2114680050 BOLT, THROUGH 2
17 * 11437179070 BOLT M 6X 37 2
18 * X2114274200 COVER, TERMINAL 1
19 26106100302 BOLT M10X 30 PLATED 2
20 11435178251 DYNAMO ASSY. ..............................................1 ............ INCLUDES ITEMS W/ $
21 $ 11435178751 STATOR ASSY. 1
22 $ 11435178761 WHEEL, DYNAMO 1
23 16071078710 CLAMP, CORD 1
24 26106060122 BOLT M 6X 12 PLATED 1
25 26476060202 BOLT M 6X 20, TAPPING 3
26 26577060142 SCREW M 6X 14 3
27 26716080002 NUT M 8 1
28 16097077350 RECTIFIER 1
29 26106060122 BOLT M 6X 12 PLATED 1
30 18335077400 WIRE, LEAD 1
YANMAR L-70EE — STARTING MOTOR AND DYNAMO ASSY.
