MVH306D/DS PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #11 (02/04/14) — PAGE 47
BATTERY ASSY. (OPTION)
NO. PART NO. PART NAME QTY. REMARKS
3 464216660 CRADLE, BATTERY 1
4 456447590 RUBBER PLATE (E) 28X240X5 1
5 456447600 RUBBER PLATE 50X240X10 2
6 014210020 SOCKET HEAD BOLT 10X20 T 2
7 030210250 WASHER, LOCK M10 2
8 604010240 BATTERY 46B24L 1
9 955300490 BATTERY TERMINAL (-) 1
10 955300470 TERMINAL COVER (-) 1
11 955300480 BATTERY TERMINAL (+) 1
12 955300460 TERMINAL COVER (+) 1
13 464117860 COVER, BATTERY 1
14 464457410 FIXED PLATE, BATTERY COVER 2
15 001220825 BOLT 8X25 T 4
16 030208200 WASHER, LOCK M8 4
17 464457390 BATTERY BOLT 2
18 022710809 NYLON NUT M8 2
19 031108160 WASHER, FLAT M8 2
20 464343740 HOLDER, BATTERY 1
41 955300680 IGNITION SWITCH ASSY. 1
41A 955000010 IGNITION KEY 1
41B 953406090 GROMMET 26D 1
BATTERY ASSY. (OPTION)
