MVH306D/DS PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #11 (02/04/14) — PAGE 59
CRANKSHAFT, PISTON & CAMSHAFT ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 71488014580 CAMSHAFT (D) ASSY 1
6 11425014200 TAPPET 2
7 11477114260 TAPPET, F.O. 1
8 11435014450 ROD, PUSH 2
12 71487621730 CRANKSHAFT ASSY 1
25 10385401221 NUT M16 1
26 11425021550 WASHER, FLYWHEEL 1
29 11488121590 FLYWHEEL W/RING GEAR ............................ 1 ................. INCLUDES ITEMS W/ #
32 # 11436221600 GEAR, RING 1
33 22512040120 KEY 4X 12 1
34 71487222720 PISTON W/RINGS .......................................... 1 ................. INCLUDES ITEMS W/ *
36 * 71487022500 RING SET, PISTON 1
42 11439922300 PISTON PIN 1
43 22252000210 CIRCLIP 21 2
44 71438023700 ROD ASSY, CONNECTING ............................ 1 ................. INCLUDES ITEMS W/ $
47 $ 11820023200 BOLT, ROD 2
48 $ 11438023100 BUSH, PISTON PIN 1
49 $ 71438023600 BEARING, CRANK PIN 1
51 71435028520 SHAFT ASSY, BALANCER 1
55 24101062024 BALL BEARING 2
56 16084221150 KEY 6.3X50 1
57 16084221250 BOLT 7/16 — 20UNF 1
58 16084221260 WASHER 1
59 71438023610 BEARING, PIN (U.S = 0.25) ............................ 1 .......... UNDER SIZED(U.S.=0.25)PART
61 71438023620 BEARING, PIN (U.S = 0.50) ............................ 1 .......... UNDER SIZED(U.S.=0.50)PART
YANMAR L-70EE — CRANKSHAFT, PISTON, CAMSHAFT ASSY.
