MVH306D/DS PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #11 (02/04/14) — PAGE 67
FUEL TANK & FUEL LINE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 71435055711 TANK, FUEL (RED) (50) ................................. 1 ............. INCLUDES ITEMS W/ *
3 * 11428855040 CAP ASSY, TANK ........................................... 1 ............. INCLUDES ITEMS W/ #
5 * # 11428855080 VALVE 1
6 * 11425055100 STRAINER, FUEL 1
7 * 11435055150 PIPE, GAUGE 1
8 * 11425055201 DAMPER. FUEL TANK 4
9 * 10385455220 CLAMP 2
10 * 23414080000 GASKET 8, ROUND 1
11 * 10530055080 PLUG, DRAIN 1
12 11425055121 FILTER, FUEL 1
13 11425055130 GASKET 1
14 11429955210 STAY 1
15 11439955230 STAY (B) 1
16 11425055300 COCK ASSY, FUEL ........................................ 1 ............. INCLUDES ITEMS W/ $
17 $ 24341000150 O - RING 1A S-15.0 1
18 11465055810 BOLT, LIFTING 1
19 22117080000 WASHER 8 1
20 26106080452 BOLT M 8X 45 PLATED 1
21 26366060002 NUT M 6 2
22 26476060142 BOLT M 6X 14, TAPPING 2
23 10699044660 CLIP, HOSE 2
24 12472259050 CLAMP 9 2
25 11425059060 PIPE, FUEL RETURN 1
26 11426859061 PIPE, FUEL 1
YANMAR L-70EE — FUEL TANK AND FUEL LINE ASSY.
