MVH306D/DS PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #11 (02/04/14) — PAGE 63
COOLING & STARTING DEVICE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 11487045201 COVER 1
2 11435045320 RUBBER, SEAL 1
3 11435045340 COLLAR 1
4 18372055210 GROMMET 1
5 26106060202 BOLT M 6X 20 PLATED 1
6 11436045101 CASE, FAN (SILVER) (17) 1
7 11425045301 RUBBER, CUSHION 4
8 11425045310 COLLAR 4
9 11425045330 SEAL, FAN CASE 1
10 11437045351 BOLT, FAN CASE 4
11 11488076050 STARTER ASSY, RECOIL ............................. 1 ................. INCLUDES ITEMS W/ *
12 * 11488076250 RECOIL ASSY ............................................... 1 ................. INCLUDES ITEMS W/ +
13 * + 11488076510 CASE, STARTER 1
14 * + 16081076520 REEL, RECOIL 1
15 * + 16084076530 RATCHET 1
16 * + 16081076540 SPRING, SPIRAL 1
17 * + 16084076560 SPRING, FRICTION 1
18 * + 16081076580 PLATE, FRICTION 1
20 * + 16081076620 KNOB, STARTER 1
21 * + 16081076630 ROPE, STARTER 1
22 * + 18113076680 NUT 1
23 * + 18113076700 WASHER 1
24 * + 11435076590 PULLEY, STARTER 1
25 26106060082 BOLT M 6X 8 PLATED 4
26 26106060122 BOLT M 6X 12 PLATED 3
27 11425076600 PLUNGER 1
28 11425076610 HOLDER, PLUNGER 1
YANMAR L-70EE — COOLING AND STARTING DEVICE ASSY.
