II.B. Installing the Stainless Steel Faucet
7
Mounting the Faucet
1. Note that the blue tubing is attached to the faucet.
2. From the sink / counter top, place over the faucet hole:
a. The larger soft black rubber washer
b. The cover plate
c. The smaller soft black rubber washer
3. From under the sink, slide over the blue tubing:
a. the black plastic (hard) washer (with the small side up)
b. lock washer
c. the wing nut
4. Hand tighten the wing nut to secure the faucet. Using vice grips, secure the wing nut and
faucet below the sink.
5. From above the sink, (CAUTION: protect the faucet base from scratching) using an 8"
adjustable wrench, turn the faucet base clockwise until firm. Then remove the vise grips from
below the sink.
To operate your Multi-Pure Faucet, just turn the handle on for continuous flow. To stop flow, return the handle to its
original position.
The faucet is now ready to be connected to your drinking water unit.
See Section V.A.
small black washer
large black washer
Cover Plate
Lock Washer
Blue Tubing
Plastic Washer
Wing Nut
COUNTERTOP
Complete Faucet Assembly
with Blue Tubing
MC650
