C o n n e c t c l e a r t u b i n g t o p l u m b i n g - - O p t i o n A o r B
Item # Part # Part Description
1 MC650 Faucet assembly with blue
tubing attached
2 MC232 Clear tubing -connects inlet adapter to
plumbing
3 MC1415 Elbow adapter - connects to blue tubing
to faucet
4a MC730 Large Straight adapter - connects to
elbow stem
4b MC1413 Elbow stem - connects to MC730
5 MCL500 Housing top
Item # Part # Part Description
6 MC253BS V-band with knob
7 CB11As Carbon Block Filter
8 MC351 O-ring
9 MCB880R Housing bottom
10 MC930ASBL Adapta Valve assembly
11 MC722 Tubing adapter
12 MC252 Black Rubber Cushion (inside housing top)
13 MC780 Wing nut
14 MC126 Bracket (not shown)
4
2
cold cold
sink sink
riser
Adapta Valve
1/2” configuration
1/2” slip joint nut
No slip joint nut at
angle stop valve
angle stop valve angle stop valve
Water supply line with
Adapta Valve in 3/8” configuration
Water supply line with
Adapta Valve in 1/2” configuration
A.
B.
riser
1/2” slip joint nut
3/8” slip joint nut
Adapta Valve
3/8” configuration
MP 880SB Installation Overview & Part Numbers I.B.
OR
2
2
11
11
10
10
blue tubing
from faucet
v-band
knob
4b
4a
5
9
8
7
6
3
12
13
1
