18

Connecting and Configuring your Router

Connecting and Configuring your Router

Access Point Mode Installation

1. Mode Selecting the Access Point Mode

1. Mode Selecting the Access Point Mode

1.1

Select “Access Point Mode”.
Click “Next”.

1.2

Move the center of the switch on
the back panel to align with the
word “AP”. Click “Next”.

2. Connect Connecting the Cables

. Connect

2.1

Connect one end of the included
Ethernet cable to the Router (which
is now functioning in Access Point
Mode) and the other end to a
cable/DSL modem. Next, plug the
included power supply into the
Router and click “Next”.
