MTS Series 249 Swivels User Manual
Page 3
Series 249 Rod Swivel Product Manual
3
Contents
How to Get Technical Support 5
Before You Contact MTS 5
If You Contact MTS by Phone 6
Problem Submittal Form in MTS Manuals 7
Series 249 Rod Swivel Component Identification 14
Series 249 Rod Swivel Functional Description 15
Series 249 Rod Swivel Specifications 16
Model 249.12 Dimensions 18
Model 249.20 Dimensions 19
Model 249.23 Dimensions 20
Model 249.32 Dimensions 21
Model 249.41 Dimensions 22
Model 249.42 Dimensions 23
Model 249.51 Dimensions 24
