Introduction, Introduction 13 – MTS Series 249 Swivels User Manual
Page 13
Series 249 Rod Swivel Product Manual
Introduction
13
Introduction
The MTS Series 249 Swivels allow hydraulic actuators to operate with a degree
of movement. Two types of swivels are available, which allow the use of swivels
at each end of an actuator. The following figure shows both types of swivels.
Contents
Series 249 Rod Swivel Component Identification 14
Series 249 Rod Swivel Functional Description 15
Series 249 Rod Swivel Specifications 16
Series 249 Swivels
Base Swivel
Rod End Swivel
