Specifications
AHX800 High Elongation Extensometer Product Manual
Introduction
7
Specifications
P
ARAMETER
S
PECIFICATION
Usable travel
800 mm (31.5 in)
Gage lengths
10 - 125 mm (0.375 - 5 in)
Measurement resolution
0.004 mm (0.00016 in)
Maximum arm opening
40 mm (1.57 in)
Knife edges
Flat
Round
Rubber
Sharpened
Knife attachment method
Adjustable mechanical spring
Weight
Approximately 9.5 kg (20.9 lb)
Environmental
For indoor use only
Temperature
5 to 40
°C
Relative humidity
10 to 85%, noncondensing
Altitude
For use at altitudes up to 2000 m (6500 ft)
Supply voltage
+ 5 V DC, 100 mA
Conforms to European CE Directives
