Installation, Installation 17 – MTS Series 315 Load Frame User Manual
Page 17
Series 315 Load Frame
Installation
17
Installation
This section describes how to install the Series 315 Load Frame.
Contents
Lifting and Moving Instructions 18
Prerequisite
You will need a fork lift or overhead crane capable of lifting the load
frame. Ensure the lifting equipment can accommodate the weight of the
load frame, see the following table.
Procedure
Perform the following to install the load frame.
1. Unpack the load frame. Go to
on page 19 to unpack and
move the load frame.
2. Connect the cables between the load frame and controller. Go to
on page 23 to make the various controller connections. Return to this
procedure when done.
3. Connect the hydraulic hoses between the load frame and hydraulic
service manifold. Go to
on page 24 to connect the
load frame to your hydraulic supply system. Return to this procedure when
done.
315 Load Frame Weights
Model
Weight
315.01
2359 kg (5200 lb)
315.02
3855 kg (8500 lb)
315.03
6350 kg (14,000 lb)
315.04
7590 kg (16,700 lb)
