Specification
Series 316 Load Frame Product Information Introduction 9
Specification
The Series 316 load frames are freestanding and the weight of the frames are
distributed adequately to prevent overload of most laboratory floors. Isolation
pads are provided with the load frames.
This table lists dimensions and weights of the standard 316 Load Frames.
316 Load Frame Specifications (part 1 of 2)
S ERIES 316.01 S ERIES 316.02 S ERIES 316.03 S ERIES 316.04
Actuator 243.40S 243.60S 243.70S 243.80S
Compression kN(kip) 496(111) 1013(227) 1459(328) 1984(446)
Tension kN(kip) 291(65) 648(145) 961(216) 1334(300)
Actuator Displacement
mm(in)s 100(4) 100(4) 100(4) 100(4)
Load Frame Spring Rate:
N/m 1.1x10^9 2.6x10^9 2.6x10^9 3.0x10^9
Lb/in 6.2x10^6 1.5x10^7 1.5x10^7 1.7x10^7
Parallel alignment Between
platens 0.051(0.002) 0.051(0.002) 0.051(0.002) 0.051(0.002)
