Installation, Installation 21 – MTS Model 680-01 High-Temperature Grips User Manual
Page 21

Model 680.01 High-Temperature Grips
21
Installation
This section describes how to install the Model 680.01 High Temperature Grips
into a load unit.
Contents
Install the Hand-Operated Hydraulic Pump 25
Grip Water Cooling Assembly Configurations for Servohydraulic Frames
29
Typical installation
The following diagram shows the main steps to install the grips. Usually the grips
are installed along with a furnace. In such cases, these instructions should be
used in conjunction with those provided for the furnace.
Typical Grip Installation
➊
➋
➌
Install the Grips
Install the Hand-
Operated
Hydraulic Pump
Install the
Cooling Kit
Preload the Spiral
Washers
➍
