PROTOCOL CONVERTER MODEL A/S-4
14
4.2 How to Set Terminal Port Switches for Different Devices
DEVICES
VDU or
Async Modem
Centronics
Tally printer
“Y” VDU,
DTE
or DCE device
Printer
Data Products
Printer
(Busy on 20)
(Busy on 19)
Cable
Switch 2
Switch 2
Switch 2
Switch 2
Switch 2
1 OFF
1 OFF
1 OFF
1 OFF
1 OFF
2 OFF
2 ON
2 OFF
2 OFF
2 OFF
3 OFF
3 OFF
3 OFF
3 OFF
3 ON
4 OFF
4 OFF
4 OFF
4 ON
4 OFF
5 ON
5 OFF
5 ON
5 OFF
5 OFF
6 ON
6 ON
6 ON
6 ON
6 OFF
7 ON
7 ON
7 ON
7 ON
7 OFF
8 OFF
8 OFF
8 OFF
8 OFF
8 OFF
Switch 3
Switch 3
Switch 3
Switch 3
1 OFF
1 ON
1 OFF
1 OFF
2 ON
2 OFF
2 ON
2 ON
3 ON
3 OFF
3 ON
3 ON
4 OFF
4 ON
4 OFF
4 OFF
5 OFF
5 ON
5 ON
5 OFF
6 ON
6 OFF
6 OFF
6 ON
7 OFF
7 OFF
7 OFF
7 OFF
8 OFF
8 OFF
8 OFF
8 OFF
Switch 6
Switch 6
Switch 6
Switch 6
1 ON
1 ON
1 ON
1 ON
2 OFF
2 OFF
2 OFF
2 OFF
3 ON
3 ON
3 ON
3 ON
4 OFF
4 ON
4 OFF
4 OFF
5 ON
5 OFF
5 ON
5 ON
OKIDATA
Products
(Busy on 11)
Switch 2
Switch 8
1 OFF
9 ON
2 OFF
10 ON
3 ON
4 OFF
5 OFF
6 ON
Switch 9
7 ON
8 OFF
4 OFF
