FGW900 High-temperature Furnace Product Manual 13
Operating condition requirements
Introduction
Operating condition requirements
Only use the high temperature furnace under the following conditions.
Technical parameters
P ARAMETER S PECIFICATION
Condition For indoor application only
Operating Temperature 5 ~ 40 ° C (41 ~ 104 °F )
Operating Humidity 5-85%, noncondensing
Maximum Altitude 2000 m (6562 ft)
Voltage Single-phase AC 200 ~ 240 V
Frequency 50 Hz / 60 Hz
Current 15 Amps
M ODEL
FGW900
Scope of application C45, C64
Temperature scope ( ° C) 300 ~ 1100(572 ° F to 2097 °F)
External dimension (mm) Φ310 x 410(12.2 in x 16.1 in)
Dimension of chamber (mm) Φ100 x 320(3.9 in x 12.6 in)
Controller size (mm) 400 x 420 x 200(15.7 in x 16.5 in x 7.9 in)
Uniform temperature zone length(mm) 100(3.9 in)
Temperature gradient ≤3 ° C(≤37.4 ° F)
Heating method Three-segment controllable
Temperature fluctuation ≤± 2 ° C(≤35.6 ° F)
Precision of temperature controller Class 0.3
Time to obtain operating temperature ≤50 min
Weight 25 kg(55.1lb)
