13
ConSoLe ControL DeSCriPtionS
MK-6000 SaW ConSoLe ControL
Decal name Function
A Ignition Switch Use to start engine (Glow-OFF-ON-START).
B Engine Throttle Controls engine speed.
C Engine Temp Gauge Shows temperature of engine.
D Lifting Points Used to lift saw.
E Engine Tachometer Shows the engine RPM’s.
F Indicator Lights Indication of Oil Pressure, Charge and Glow Plug.
G Fuel Gauge Shows the level of fuel in the fuel tank.
h Depth Stop Sets the depth stop for repetitive cuts at the same depth.
I Radiator Filled with engine coolant
J Depth Indicator Displays cutting depth.
K T-handle Knob Use to tighten operator grip handles.
L handle Grip For operator gripping.
M Fuel Tank Fill Fill the fuel tank at this location.
N Raise/Lower handle Controls raising and lowering of blade.
O Temp Gauge Reset Must be reset after overheat condition
P FNR handle Used to set direction of saw (Forward/Neutral/Reverse).
Q Water Valve Lever Controls water flow to blade guard.
R Back Panel Knob 1/4 Turn Fastener to remove back.
S Water Inlet hook-up for standard water hose.
T E-Stop Stops down engine in an emergency!
U Point Lift Cable Allows operator to lift pointer.
V Neutral Engages Transmission, Turn-To-Lock.
Engagement handle
