BX-4 29
4. MOTOR-BRUSH REPLACEMENT:
• Insert a screwdriver into the Motor Brush
Cap. Rotate counter-clockwise and remove the
Cap. Repeat on the other side of the Motor.
• Remove the Motor Brush. Clean the Brush Housing
of all carbon dust and fragments.
• Align a new Motor Brush with the Brush Housing. Insert
the new Motor Brush.
• Replace the Motor Brush Cap. Using the screwdriver,
rotate clockwise to secure in place.
• Using this same method, install a new Motor Brush
on the other side of the Motor.
MAINTENANCE & TROUBLESHOOTING
Disconnect the tool before servicing and when changing
accessories, such as blades, bits, cutters, and the like.
WARNING
