MK-1080 PAVER SAW PARTS LIST
PAVER SAW, MK-1080 ASSY, MOTOR MOUNT, 166878
ITEM
NO.
DESCRIPTION
PART OR
IDENTIFYING NO.
QTY.
REQ.
1 FLANGE, OUTER 135830 1
2 NUT, HEX, 5/16-18 135848 1
3 BEARING, BALL, 17 X 40 X 12 MM 137711 2
4 FLANGE, Ø2-3/8 INNER 137737 1
5 KEY, 3/16 SQ X 1-1/8 150344 1
6 WASHER, 3/8 SAE FLAT 150923 3
7 WASHER, 3/8 SPLIT LOCK 150925 1
8 SCREW, 5/16-18 X 1 HEX HEAD MACHINE 151743 4
9 BOLT, HEX HD TAP, 5/16-18 X 2-1/2 151748 1
10 STRAP, 1 INCH MOTOR ADJ. 152673 1
11 BUMPER, RUBBER, 1/2 DIA 152674 1
12 BOLT, 3/8-16 X 3-1/2 HEX HEAD TAP 153147 1
13 PIVOT, BLADE GUARD 153208 1
14 SCREW, HEX HD CAP, 3/8-16 X 2 153485 1
15 SCREW, 5/16-18 X 3/8 SOCKET HEAD SET 157083 2
16 PULLEY, 6J19 X 5/8 BORE 158199 1
17 BUTTON, SHAFT LOCK 158200 1
18 SPRING, BLADE SHAFT LOCK 158201 1
19 RING, 1/4 E-STYLE RETAINING 158202 1
20 SHAFT, BLADE 158222 1
21 BUSHING, 3/4 ID FLANGED 159207 2
22 NUT, 3/8-16 HEX 159863 2
23 MOUNT, MOTOR (COMP) 166879 1
