Page 40
40
iteM
DesCRiPtiON
QtY
PaRt #
D21
Boot, Thermal Overload Switch
1
167983
D22
Switch, 15A\125V Lighted Rocker
1
153421
D23
Rectifier, 40 Amp
1
153677
D24
Screw, 10-24 x 3/4 Fillister Head Machine
1
151750
D25
Wire-nut, 3/#16 AWG (Blue)
1
155492
D26
Tag, 660 Serial Number
1
156561
D27
Label, Caution Strip
1
155214
D28
Label, When Motor Cools…
1
154409
E
Frame
1
n/a
E1
Frame
1
153322
E2
Pan, Plastic
1
151736
E3
Plug, Water Drain
1
153439
E4
Plate, Adjustment
2
151758
E5
Pin, Rolled
2
151783
F
Guide Bar, 5/8 Dia.
1
151739-MK
F1
Bar, Guide, 5/8 Dia.
1
151739
F2
Cover, Guide Bar
1
151740
F3
Spacer, 5/8 Guide Bar Cover
2
151755
F4
Screw, 5/16-18 x 1 Hex Head Cap
2
151743
F5
Washer, 5/16 Split Lock
2
151747
F6
Washer, 5/16 SAE Flat
2
151754
G
Linear Bearing
1
151737-MK
G1
Casting, Bearing, Linear
1
151737
G1a
Bearing, Multi-Lube
2
151781
G2
Screw, 5/16-18 x 1 Hex Head Cap
2
151743
G3
Washer, 5/16 Split Lock
2
151747
G4
Washer, 5/16 SAE Flat
2
151754
H
Post
1
n/a
H1
Post, Rear, 660
Shaft, 5/8 Pivot, 660
1
1
153451
153452
H2
Screw, 3/8-16 x 2 Hex Head Cap
2
153485
H3
Screw, 3/8-16 x 1 Hex Head Cap
1
152507
H4
Washer, 3/8 Split Lock
3
150925
H5
Washer, 3/8 SAE Flat
4
150923
H6
Knob, 3/8-16 x 1-1/2 MK Adjustment
1
156770-02
J
Roller Wheel
1
151756
J1
Bracket, Roller Wheel
1
154021
J2
Wheel, Roller
1
151799
J3
Screw, 1/4-20 x 1 1/2 Hex Head Cap
1
151914
J4
Washer, 1/4 SAE Flat
1
151915
J5
Nut, 1/4-20 Hex
1
151893
K
Table, 660
1
n/a
K1
Table, 660
1
152680
K2
Screw, 5/16-18 x 1 Hex Head Cap
2
151743
K3
Washer, 5/16 Split Lock
2
151747
K4
Washer, 5/16 SAE Flat
2
151754
MK-660 tile saw
PaRts list
