PF/I-6 © Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
F
lush
F
ace
/ I
nterIor
l
Iner
s
erIes
Tl-17 s
eCTion
P
roPerTies and
l
oad
T
ables
1 1 /
2
"
C
12" Coverage
1. Theoretical section properties have been calculated per AISI 2001 “Specification for the Design of Cold-formed Steel Structural Members.” Ixx and Sxx are
effective section properties for deflection and bending.
2. Allowable load is calculated in accordance with AISI 2001 specifications considering bending, shear, combined bending and shear, deflection, and panel
testing. Allowable load considers the worst case of 3 and 4 equal span conditions. Allowable load does not address web crippling or fasteners/support
connection or panel disengagement. Panel weight is not considered.
3. Deflection is limited to L/180.
4. Allowable loads do not include a 1/3 stress increase.
ALLOWABLE UNIFORM LOADS PSF
(3 or More Equal Spans)
2’ 3’ 4’ 5’ 6’ 8’ 2’ 3’ 4’ 5’ 6’ 8’
SECTION PROPERTIES
Bottom in Compression
Width
(in.)
Yield
KSI
12” 50
12” 50
12” 33
12” 33
24
Ga.
22
20
18
Sxx
In 3 /ft
Ixx
In 4 /ft
Weight
PSF
1.34
1.77
2.10
2.76
Top in Compression
Sxx
In 3 /ft
Ixx
In 4 /ft
0.0495 0.0562 0.0746 0.0597 302 145 84 54 38 22 288 137 79 51 36 20
0.0724 0.0860 0.1025 0.0821 409 197 115 75 52 30 29 29 29 29 0 0
0.0986 0.1268 0.1294 0.1043 335 163 95 62 44 25 29 29 29 29 0 0
0.1480 0.1805 0.1790 0.1446 453 224 131 86 60 134 29 29 29 29 0 0
Inward Load Outward Load
 Substructure
 Coverage
 Length
 Fasteners
 Availability
GENERAL INFORMATION ATTACHMENT DETAIL
TL-17 panels are designed to be utilized over open
structural framing or a solid substrate.
TL-17 panels are available in a 1 1 /
2
" depth with a 12" width
coverage.
Minimum factory cut length is 5'-0".
Maximum available panel length is 22'-0".
The fastener selection guide should be consulted for
choosing the proper fastener for specific applications.
Quantity and type of fastener must meet necessary loading
and code requirements.
NOTE: All panels are subject to surface distortion due to
improperly applied fasteners. Overdriven fasteners will
cause stress and induce oil canning across the face of the
panel at or near the point of attachment.
Finishes: Kynar 500 (PVDF) standard; optional: multi-pass
Kynar 500, Marblique, Plastisol, and Polyester
Gauges: 24ga, 22ga, 20ga, and 18ga
*Pre-drilling into thicker steel may be required.
Field-Applied Sealant
#10-12 x 1" Pancake Head Woodscrew
(wood substrate)
or
#10-16 x 1" Pancake Head Driller
(steel substrate)*
FASTENING PATTERNS
#10-12 x 1" Pancake Head Woodscrew
(wood substrate)
or
#10-16 x 1" Pancake Head Driller
(steel substrate)*
Field-Applied Sealant
