Metal Sales PBU-Panel - Manual (Page 12)

PUP-12
U-PANEL
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
U-Panel
v
alley
d
eTail
s
CUlPTUred
r
ake
d
eTail
1:12 Slope
Minimum
U-Panel (bevel cut in field)
1 /
4
"-14 x 7 /
8
" Stitch (1'-0" o.c.)
PBU-Panel
Tape Sealant
#12-14 x 1 1 /
2
" SD (see below)
U-Panel Sculptured Rake
Tape Sealant
U-Panel Outside Closure
1 /
4
"-14 x 7 /
8
" Stitch XL (1'-0" o.c.)
1:12 Slope
Minimum
#12-14 x 1 1 /
2
" SD (see below)
Tape Sealant
Classic Rib Inside Closure
Valley Plate
Valley
3" Minimum
PBU-Panel Fastening Pattern
Tape Sealant (roof only)
#12-14 x 1 1 /
2
" SD
1 /
4
"-14 x 7 /
8
" Stitch (1'-0" o.c.)
PBU-Panel Fastening Pattern
Tape Sealant (roof only)
#12-14 x 1 1 /
2
" SD
1 /
4
"-14 x 7 /
8
" Stitch (1'-0" o.c.)
