U-panel, U-panel e – Metal Sales PBU-Panel User Manual
Page 11
PUP-11
U-PANEL
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
U-Panel
e
ave
d
eTail
b
ox
g
UTTer
d
eTail
1:12 Slope
Minimum
1:12 Slope
Minimum
1
/
4
"-14 x
7
/
8
" Stitch (1'-0" o.c.)
PBU-Panel
Tape Sealant
Eave
#12-14 x 1
1
/
2
" SD (see below)
U-Panel Inside Closure
Tape Sealant
#12-14 x 1
1
/
2
" SD (see below)
U-Panel Outside Closure
U-Panel
1
/
8
" -
3
/
16
" Pop Rivet (every gutter support)
PBU-Panel
Tape Sealant
Gutter Support
#12-14 x 1
1
/
2
" SD (see below)
U-Panel Inside Closure
Tape Sealant
#12-14 x 1
1
/
2
" SD (see below)
U-Panel Outside Closure
Box Gutter
U-Panel
Tape Sealant
PBU-Panel Fastening Pattern
Tape Sealant (roof only)
#12-14 x 1
1
/
2
" SD
1
/
4
"-14 x
7
/
8
" Stitch (1'-0" o.c.)
PBU-Panel Fastening Pattern
Tape Sealant (roof only)
#12-14 x 1
1
/
2
" SD
#
1
/
4
-14 x
7
/
8
" Stitch (1'-0" o.c.)
