background image

PRP-8

© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11

800.406.7387 (Corporate Office) • www.metalsales.us.com

R-PANEL

r-P

anel

s

eCTion

P

roPerTies

and

g

eneral

i

nformaTion

C

12"

1

1

/

4

"

3

5

/

16

"

2

1

/

16

"

4"

36" Coverage

3

/

4

"

1"

1

7

/

16

"

ALLOWABLE UNIFORM LOADS PSF

(3 or More Equal Spans)

2’ 3’ 4’ 5’ 6’ 7’ 2’ 3’ 4’ 5’ 6’ 7’

SECTION PROPERTIES

Bottom in Compression

Width

(in.)

Yield

KSI

36”

80

36”

50

36”

50

26

Ga.

24
22

Sxx

In

3

/ft

Ixx

In

4

/ft

Weight

PSF

0.87
1.13
1.45

Top in Compression

Sxx

In

3

/ft

Ixx

In

4

/ft

Inward

Load

Outward

Load

0.0350

0.0348 0.0293 0.0439

235 119 71 47 27 17 270 132 77 50 35 26

0.0543 0.0558 0.0427 0.0595

316 147 85 55 38 27 398 185 106 68 48 35

0.0767 0.0814 0.0600 0.0790

434 199 113 73 51 37 594 273 155 100 70 51

1. Theoretical section properties have been calculated per AISI 2001 “Specification for the Design of Cold-formed Steel Structural Members.” Ixx and Sxx are

effective section properties for deflection and bending.

2. Allowable load is calculated in accordance with AISI 2001 specifications considering bending, shear, combined bending and shear, deflection, and applicable

testing when available. Allowable load considers the worst case of 3 and 4 equal span conditions. Allowable load does not address web crippling or

fasteners/support connection and panel weight is not considered.

3. Deflection consideration is limited by a maximum deflection ratio of L/180 of span.

4. Allowable loads do not include a 1/3 stress increase in uplift.

GENERAL INFORMATION

ATTACHMENT DETAIL

FASTENING PATTERNS

R-Panel is designed to be utilized over open structural

framing but can easily be used with a solid substrate. To

avoid panel distortion use a properly aligned and uniform

substructure.

R-Panels are available in a 1

1

/

4

" rib height with a coverage

width of 36".

Minimum factory cut length is 5'-0". Maximum

recommended panel length is 45'-0". Longer panels

require additional consideration in packaging, shipping, and

erection. Please consult Metal Sales for recommendations.

The fastener selection guide should be consulted for

choosing the proper fastener for specific applications.

Quantity and type of fastener must meet necessary loading

and code requirements.

NOTE: All panels are subject to surface distortion due to

improperly applied fasteners. Overdriven fasteners will

cause stress and induce oil canning across the face of the

panel at or near the point of attachment.

Finishes: Acrylic Coated Galvalume

®

, MS Colorfast45

®

,

or various Kynar 500 (PVDF) colors.

Gauges: 26ga and 24ga standard, 22ga optional

#12-14 x 1

1

/

4

" Self Driller

End of Panel

Field of Panel

Substructure

Coverage

Length

Fasteners

Availability

#12-14 x 1

1

/

4

" Self Driller

#12-14 x 1

1

/

4

" Self Driller
