R-PANEL
r-Panel o
uTside
C
orner
d
eTail
g
ravel
s
ToP
d
eTail
R-Panel
Tape Sealant
Fastener (by others)
#12-14 x 1 1 /
2
" SD (see below)
R-Panel Outside Closure
1 /
4
"-14 x 7 /
8
" Stitch (every rib)
Gravel Stop
Tape Sealant
R-Panel
R-Panel Outside Corner
1 /
4
"-14 x 7 /
8
" Stitch (1'-0" o.c.)
Tape Sealant
1:12 Slope
Minimum
R-Panel Fastening Pattern
#12-14 x 1 1 /
2
" SD
1 /
4
"-14 x 7 /
8
" Stitch (1'-0" o.c.)
Tape Sealant (roof only)
