Metal Sales PBR-Panel - Manual (Page 13)

PRP-13 © Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
r-Panel
R-PANEL v
alley
d
eTail
s
CulPTured
r
ake
d
eTail
1:12 Slope
Minimum
PBR-Panel
Valley Plate
#12-14 x 1 1 /
2
" SD (see below)
Tape Sealant
Universal Closure
3" Minimum
Valley
PBR-Panel
Tape Sealant
R-Panel Sculptured Rake
#12-14 x 1 1 /
2
" SD
# 1 /
4
-14 x 7 /
8
" Stitch (every rib)
Tape Sealant
Rake Angle
#12-14 x 1 1 /
2
" SD (see below)
R-Panel
R-Panel Outside Closure
1 /
4
"-14 x 7 /
8
" Stitch (1'-0" o.c.)
1:12 Slope
Minimum
CL
R-Panel Fastening Pattern
#12-14 x 1 1 /
2
" SD
1 /
4
"-14 x 7 /
8
" (1'-0" o.c.)
Tape Sealant (roof only)
R-Panel Fastening Pattern
#12-14 x 1 1 /
2
" SD
1 /
4
"-14 x 7 /
8
" Stitch (1'-0" o.c.)
Tape Sealant (roof only)
