Corrugated – Metal Sales 7/8 Corrugated User Manual
Page 14
P7/8-14
7
/
8
" CORRUGATED
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
i
nsiDe
C
orner
D
eTail
J
amb
D
eTail
Tape Sealant
Inside Corner
7
/
8
" CorrugaTeD
Jamb
7
/
8
" Corrugated Wall Panel
7
/
8
" Corrugated Wall Panel
1
/
4
"-14 x
7
/
8
" Stitch Screw (1'-0" o.c.)
#12-14 x 1
1
/
4
" Self Driller
#12-14 x 1
1
/
4
" Self Driller (1'-0" o.c.)
