Metal Sales 7/8 Corrugated - Manual (Page 11)

P7/8-11
7 /
8
" CORRUGATED
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
r
akewall wiTh
w
all
P
anel
D
eTail
e
nDwall wiTh
w
all
P
anel
D
eTail
1:12 Slope
Minimum
Tape Sealant
Rakewall
7 /
8
" CorrugaTeD
1:12 Slope
Minimum
Closure
Tape Sealant
Pitch Break
Closure
7 /
8
" Corrugated Roof Panel
7 /
8
" Corrugated Wall Panel
7 /
8
" Corrugated Roof Panel
7 /
8
" Corrugated Wall Panel
#12-14 x 2" Self Driller (1'-0" o.c.)
#12-14 x 1 1 /
4
" Self Driller (See Below)
Rake Angle
#12-14 x 2" Self Driller (See Below)
#12-14 x 1 1 /
4
" Self Driller
Tape Sealant
#12-14 x 2" Self Driller
7 /
8
" Corrugated Roof Fastening Pattern
Tape Sealant
#12-14 x 2" Self Driller
7 /
8
" Corrugated Roof Fastening Pattern
