Memmert IPS Peltier-cooled incubators - Manual (Page 13)

D24034 | Date 10/2014 13
Construction and description
2.7 Technical data
Appliance IPP IPS
Appliance size 30 55 110 260 750 260 750
Appliance width D Appliance width D 1 [mm] 585 585 745 824 1224 824 1224
Appliance height E Appliance height E 1 [mm] 707 787 867 1186 1726 1186 1726
Appliance depth G Appliance depth G 1 (footprint) [mm] (footprint) [mm] (footprint) [mm] (footprint) [mm] 524 604 674 774 874 774 874
Depth of door lock [mm] Depth of door lock [mm] Depth of door lock [mm] 56
Appliance depth F 1 (including door handle)
[mm]
580 660 730 830 930 830 930
Chamber width A 1 [mm] 400 400 560 640 1040 640 1040
Chamber height B Chamber height B 1 [mm] 320 400 480 800 1200 800 1200
Chamber depth C Chamber depth C 1 [mm] 250 330 400 500 600 500 600
Chamber volume [litres] 32 53 108 256 749 256 749
Weight [kg] Weight [kg] 62 74 100 121 284 114 256
Power [W] 160 275 650 820 1200 550 550
Current consumption [A]
230 V, 50/60 Hz 0.6 1.2 2.8 3.6 5.2 2.4 2.4
115 V, 50/60 Hz 1.2 2.4 5.7 7.1 10.4 4.8 4.8
max. number of sliding shelves max. number of sliding shelves max. number of sliding shelves max. number of sliding shelves 3 4 5 9 14 9 14
max. load per sliding shelve [kg] 30
max. load per appliance [kg] max. load per appliance [kg] max. load per appliance [kg] max. load per appliance [kg] 60 80 150 200 200 300 300
Temperature
Adjustment range Adjustment range Adjustment range 0 to 70 °C 2 14 to 45 °C 2
Adjustment precision Adjustment precision Adjustment precision 0.1 K
1 see Fig. 5
2 The minimum temperature depends on the outside temperature (see ambient conditions on
page 15). If the interior is illuminated, the temperature range is further restricted.
