Construction and description
2. Construction and description
2.1 Construction
1
2
3
4 5 6
1
7
8
°C
22
.4
TEMP
°C Set 37.0
TIMER 30
m
04
h
Ende 23.Nov 13:30
LICHT
%
100
Fig. 2 Construction
1 ControlCOCKPIT with capacitive function
keys and LCD displays (see page 24)
ControlCOCKPIT with capacitive function ControlCOCKPIT with capacitive function
2 On/Off switch (see page 21)
keys and LCD displays (see page 24) keys and LCD displays (see page 24)
3 Chamber fan
On/Off switch (see page 21) On/Off switch (see page 21)
4 Steel grid
5 Interior
6 Nameplate (see page 12)
7 Door handle
Nameplate (see page 12) Nameplate (see page 12)
8 Turn control with confirmation key
