Memmert HPP Life Constant climate chambers - Manual (Page 9)

D32802 | Date 10/2014 9
Description and function
2.3 Technical data
Appliance width [mm] Appliance width [mm] Appliance width [mm] 1224
Appliance height [mm] 1726
Appliance depth [mm] 874
Depth of door lock [mm] Depth of door lock [mm] Depth of door lock [mm] 56
Appliance depth (including door handle) [mm] Appliance depth (including door handle) [mm] Appliance depth (including door handle) [mm] Appliance depth (including door handle) [mm] 930
Chamber width [mm] 1040
Chamber height [mm] 1200
Chamber depth [mm] 600
Chamber volume [litres] 749
Weight (in the box) [kg] 284
Power [W] 1200
Current consumption
[A]
230 V, 50/60 Hz 5.2
115 V, 50/60 Hz 10.4
max. number of sliding shelves max. 3 illuminated
max. load per sliding shelf [kg] 30
max. load per appliance [kg] 200
Temperature
Adjustment range 0 °C to +70 °C
Working range with illumination +5 °C to +40 °C
Adjustment precision 0.1 K
Humidity Humidity Adjustment range Adjustment range Adjustment range 10 … 90 % rh
LED light
5,500 K cold white and 2,700
K warm white, radiating up-
wards (swivel-type) wards (swivel-type)
2.4 Scope of delivery
►
Exhaust air unit
►
18 Torx screws M3x8
►
Back of the chamber
►
Assembly instructions
For more information on assembly and description and on delivery and setting up,
please refer to the operating manual for the constant climate chamber HPP.
