Model:
LED4EYES
·
Light Source:
128pcs* 5mm
super bright
LEDs( 32red
24green 24 blue
24white 24yellow)
• Extreme long
lifetime of the
LEDs (100,000 hr. rating)
144 …… 151
program
18
152 …… 159
program
19
160 …… 167
program
20
168 …… 175
program
21
176 …… 183
program
22
184 …… 191
program
23
192 …… 199
program
24
200 …… 207
program
25
208 …… 215
program
26
216 …… 223
program
27
224 …… 231
program
28
232 …… 239
program
29
240 …… 247
sound
1
248 …… 255
sound
2
ch2
0 …… 255
speed(slow to fast)
0 …… 7
no
flash
ch3
8
……
255
flash(slow to fast)
• 3 DMX Channels
• 4-Button LED DMX Display
• 3 operation modes: DMX, Sound Active & Master/Slave
• Beam angle: 50 degrees
• Power Consumption: 20W
• Multi-voltage Operation: AC 120V, 60Hz
• Dimensions (LxWxH): 312 x 306 x 334 mm
• N.W: 5 kgs.
• N.W: 6 kgs.
