USER MANUAL FLEXIPAR
1/2
USER MANUAL
FLEXIPAR
TECHNICAL SPECIFICATIONS
Power supply: 120V AC, 60HZ~
Power consumption: 600W
Dimensions: 255 x 280 x 290 mm
Net weight: 4KGS
Fitting lamp: HPL575, HX600/601, GLA575
Maximum ambient temperature: 45 0 C
Maximum housing temperature: 160 0 C
Minimum distance: 3m
Min distance form lighted object: 0.5m
Professional theatre spot
With 4 exchangeable lenses (VNSP, NSP, MFL and WFL) • Light output of a conventional PAR
with less power consumption (600 W) • High-quality die-cast housing for highest stability • With
colour-filter frame • Optional barndoors • Ideal for theatres, large stages and mobile use
INSTALLATION
Installing/Replacing the lamp
DANGER TO LIFE! Only install the lamp with the device switched off! Unplug from mains before!
CAUTION! The lamp has to be replaced when it is damaged or deformed due to the heat!
Before replacing the lamp, unplug mains lead and let the lamp cool down (approx. 5 minutes).
During the installation do not touch the glass-bulbs bare-handed! Please follow the lamp manufacturer's
notes!
Do not install lamps with a higher wattage! Lamps with a higher wattage generate temperatures the device
was not designed for. Damages caused by non-observance are not subject to warranty.
For the installation, you need one lamp.
Procedure:
Step 1
: Open the lampholder cover by loosening the fixation screw.
Step 2: If replacing the lamp, remove the old lamp from the spot.
Step 3: Insert the lamp in the lampholder .
Step 4: Insert the lampholder and close the device .
Do not operate this device with opened housing!
Overhead rigging
The installation of the projector has to be built and constructed in a way that it can hold 10 times the
weight for 1 hour without any harming deformation.
The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net.
This secondary safety attachment must be constructed in a way that no part of the installation can fall
down if the main attachment fails.
When rigging, derigging or servicing the fixture staying in the area below the installation place, on bridges,
under high working places and other endangered areas is forbidden.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert before taking into operation for the first time and after changes before taking into operation another
time.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
