TABLE 1
Inductance Percent Test Resistance Rated DC Current
L( μH) Tolerance Frequency RDC( Ω)Max. IDC1(A) IDC2(A)
1.0 M,N 100kHz/0.25V 16m 18.0 6.5 1R0
2.2 M,N 100kHz/0.25V 23m 14.0 5.0 2R2
3.3 M,N 100kHz/0.25V 26m 12.5 4.7 3R3
4.7 M,N 100kHz/0.25V 28m 11.5 4.4 4R7
5.6 M,N 100kHz/0.25V 30m 10.8 4.1 5R6
10 M,N 100kHz/0.25V 40m 8.0 3.9 100
15 M,N 100kHz/0.25V 48m 7.0 3.4 150
22 M,N 100kHz/0.25V 59m 6.0 3.1 220
33 M,N 100kHz/0.25V 75m 5.0 2.8 330
47 M,N 100kHz/0.25V 97m 4.0 2.4 470
68 M,N 100kHz/0.25V 0.138 3.0 2.0 680
100 M,N 100kHz/0.25V 0.207 2.4 1.7 101
150 M,N 100kHz/0.25V 0.293 2.1 1.3 151
220 M,N 100kHz/0.25V 0.47 1.9 1.1 221
270 M,N 100kHz/0.25V 0.64 1.4 0.95 271
330 M,N 100kHz/0.25V 0.78 1.1 0.86 331
470 M,N 100kHz/0.25V 1.08 1.1 0.73 471
680 M,N 100kHz/0.25V 1.40 0.96 0.64 681
820 M,N 100kHz/0.25V 1.70 0.88 0.58 821
1000 M,N 100kHz/0.25V 2.01 0.80 0.53 102
※ □ specify the inductance tolerance,M( ±20%),N(±30%)
※ IDC1： Based on inductance change (△L/Lo： ≦ drop 10%) @ambient temperature 25℃
IDC2： Based on temperature rise (△T： 40℃ TYP.)
Rated DC Current： The less value which is IDC1 or IDC2.
MSCDB-1507-SERIES Page-2/8
MSCDRB-1507-102□
Marking
MAGLAYERS
PT/NO.
MSCDRB-1507-680□
MSCDRB-1507-1R0□
MSCDRB-1507-2R2□
MSCDRB-1507-101□
MSCDRB-1507-3R3□
MSCDRB-1507-821□
MSCDRB-1507-151□
MSCDRB-1507-221□
MSCDRB-1507-271□
MSCDRB-1507-681□
MSCDRB-1507-331□
MSCDRB-1507-471□
MSCDRB-1507-220□
MSCDRB-1507-330□
MSCDRB-1507-470□
MSCDRB-1507-4R7□
MSCDRB-1507-5R6□
MSCDRB-1507-100□
MSCDRB-1507-150□
MAG.LAYERS
