TABLE 1
Inductance Percent Quality L,Q Freq. SRF DCR IDC
L(nH) Tolerance Min. (MHz) (MHz)Min. ( Ω) Max. (mA) Max.
MHSC-1608C-68N□ 68 G,J,K 37 200 1700 0.340 600
MHSC-1608C-72N□ 72 G,J,K 34 150 1700 0.490 400
MHSC-1608C-75N□ 75 G,J,K 34 150 1700 0.430 400
MHSC-1608C-79N□ 79 G,J,K 34 150 1700 0.500 400
MHSC-1608C-82N□ 82 G,J,K 34 150 1700 0.540 400
MHSC-1608C-91N□ 91 G,J,K 34 150 1500 0.560 400
MHSC-1608C-R10□ 100 G,J,K 34 150 1400 0.580 400
MHSC-1608C-R11□ 110 G,J,K 32 150 1350 0.610 300
MHSC-1608C-R12□ 120 G,J,K 32 150 1300 0.650 300
MHSC-1608C-R13□ 130 G,J,K 32 150 1200 0.750 280
MHSC-1608C-R15□ 150 G,J,K 28 150 990 0.920 280
MHSC-1608C-R16□ 160 G,J,K 28 150 990 1.050 260
MHSC-1608C-R17□ 170 G,J,K 25 100 990 1.150 240
MHSC-1608C-R18□ 180 G,J,K 25 100 990 1.250 240
MHSC-1608C-R19□ 190 G,J,K 25 100 990 1.350 200
MHSC-1608C-R20□ 200 G,J,K 25 100 990 1.500 200
MHSC-1608C-R22□ 220 G,J,K 25 100 900 1.600 250
MHSC-1608C-R24□ 240 G,J,K 25 100 900 1.900 200
MHSC-1608C-R25□ 250 G,J,K 25 100 900 0.234 250
MHSC-1608C-R27□ 270 G,J,K 24 100 900 2.450 170
MHSC-1608C-R30□ 300 G,J,K 25 100 900 2.700 150
MHSC-1608C-R33□ 330 G,J,K 25 100 900 2.750 100
MHSC-1608C-R34□ 340 G,J,K 25 100 900 2.900 100
MHSC-1608C-R36□ 360 G,J,K 25 100 900 3.070 100
MHSC-1608C-R37□ 370 G,J,K 25 100 900 3.100 100
MHSC-1608C-R39□ 390 G,J,K 25 100 900 3.150 100
MHSC-1608C-R47□ 470 G,J,K 25 100 750 4.000 80
※ 1. □ Specify the inductance tolerance, G( ±2%),J(±5%),K(±10%)
2. IDC:Based on temperature rise(△T=15℃ Typ.) at 25℃ ambient.
